ERW Carbon Steel Pipe Tube Sch 40 A106 SA 106 Gr B Welded

Name: ERW Carbon Steel Pipe Tube Sch 40 A106 SA 106 Gr B Welded
Brand: Zhijia
SKU: Carbon Wleded Pipe
Price: 621 USD
Availability: InStock
Rating: 5 (192 reviews)

Product Details

Place of Origin: Jiangsu

Brand Name: Zhijia

Certification: API, ce, RoHS, BIS, tisi, JIS, GS, ISO9001

Model Number: Carbon Wleded Pipe

Payment & Shipping Terms

Minimum Order Quantity: 5Tons

Price: USD 621-938 Per Ton

Packaging Details: packed into bundles or wooden box or as the customer required

Delivery Time: 10-15days

Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability: 500000 Ton/Tons per Month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                Sch 40 Carbon Steel Pipe Tube, A106 Carbon Steel Pipe Tube, Carbon Steel ERW Pipe


Standards:	ASTM, ASME And API, ANSI B 36.10	Craft:	Cold Rolled And Cold Drawn
ANSI Standard:	B1.20.	Grades:	ASTM A106 Grade A, Grade B, Grade C
Type:	ERW / Seamless / Fabricated / Welded	Size:	1/2” NB To 36” NB
Length:	Minimum 3 Meters, Maximum 18 Meters	Thickness:	3-12mm
Specialized In:	Large Diameter ASTM A106 Grade B Pipe	Schedules:	Schedule 20, 30, 40, Standard (STD), Extra Heavy (XH), 80, 100, 120, 140, 160, XXH & Heavier
ASME Standard:	B36.10M	Tolerance:	Cold Drawn Pipe: +/-0.1mm Cold Rolled Pipe: +/-0.05mm
End:	Plain End, Beveled End, Treaded

Standards:	ASTM, ASME And API, ANSI B 36.10
Craft:	Cold Rolled And Cold Drawn
ANSI Standard:	B1.20.
Grades:	ASTM A106 Grade A, Grade B, Grade C
Type:	ERW / Seamless / Fabricated / Welded
Size:	1/2” NB To 36” NB
Length:	Minimum 3 Meters, Maximum 18 Meters
Thickness:	3-12mm
Specialized In:	Large Diameter ASTM A106 Grade B Pipe
Schedules:	Schedule 20, 30, 40, Standard (STD), Extra Heavy (XH), 80, 100, 120, 140, 160, XXH & Heavier
ASME Standard:	B36.10M
Tolerance:	Cold Drawn Pipe: +/-0.1mm Cold Rolled Pipe: +/-0.05mm
End:	Plain End, Beveled End, Treaded

ERW Carbon Steel Pipe Tube Sch 40 A106 SA 106 Gr B Welded

SA 106 Gr B Sch 40 Welded Pipe, A106 Gr B Carbon Steel ERW Pipe manufacturer in China

ASTM A106 Grade B Pipe is a specification and grade for high temperature, high pressure carbon steel pipes. Zhijia Steel Company is a supplier of these pipes in different sizes and quantities. There are different standards and grades that are used in different applications. The A106 Grade B Seamless Pipe is used in applications where hot gases and fluids are transported at elevated temperatures. This is important to keep the energy consumption down at these plants. There are different pressure classes denoted by the schedules of these pipes.

Our ASTM A106 Gr B Sch 40 pipes are a medium range of pressure class pipes that can be applied in applications with mild to medium pressure capacities. The applications of the ASTM A106 Gr.B Material could be seen industries like ship building, marine applications, oil and gas refineries and in petrochemical plants. The A106 Gr.B Material produced by us is of high standard, high strength, high wear and tear resistant. The dimensions of the A106 Grade B Pipe vary with the standards and application requirements. The A106b Pipe sizes range from 1/8 inches to 48 inches in the generally used range. You can contact us for any custom made piping in SA 106 Gr B Material.

ERW Carbon Steel Pipe Tube Sch 40 A106 SA 106 Gr B Welded 0

ASTM A106 Grade B Carbon Steel Pipe Size Range

Size Range: 1/2” NB to 36” NB
Thickness: 20, 30, 40, Standard (STD), Extra Heavy (XH), 80, 100, 120, 140, 160, XXH & heavier
Grades : ASTM A106 Grade A, ASTM A106 Grade B, ASTM A106 Grade C
Applications: Oil Refineries, Petrochemicals, Power Generation (Nuclear/Thermal), Steel, Sugar, Boiler Equipments, Pressure Vessels and General Engineering Purposes

Carbon Steel A106 Seamless Pipes Price list

Size"	MSL Make	ISMT make	JSL Make
1/2"	1,323.53	1,316.18	1,330.88
3/4"	1,102.94	1,095.59	1,110.29
1"	955.88	948.53	963.24
1.25"	911.76	904.41	919.12
1.5"	808.82	801.47	816.18
Price USD/Ton All prices are applicable for SCH 40, SCH 60, SCH 80 & SCH XS

SA 106 Gr B Welded Pipes Outside Diameter

NPS [DN Designator]	Over		Under
NPS [DN Designator]	in.	mm	in.	mm
1/8 to 1-1/2 [6 to 40], incl	1/64 (0.015)	0.4	1/64 (0.015)	0.4
Over 1-1/2 to 4 [40 to 100], incl	1/32 (0.031)	0.8	1/32 (0.031)	0.8
Over 4 to 8 [100 to 200], incl	1/16 (0.062)	1.6	1/32 (0.031)	0.8
Over 8 to 18 [200 to 450], incl	3/32 (0.093)	2.4	1/32 (0.031)	0.8
Over 18 to 26 [450 to 650], incl	1/8 (0.125)	3.2	1/32 (0.031)	0.8
Over 26 to 34 [650 to 859], incl	5/32 (0.156)	4.0	1/32 (0.031)	0.8
Over 34 to 48 [850 to 1200], incl	3/16 (0.187)	4.8	1/32 (0.031)	0.8

ASTM A106 grade b seamless pipe Mechanical Tests Specified

Tensile Test -- NPS 8 and larger -- either transverse or longitudinal acceptable
Smaller than NPS 8 -- weighed in lots. Larger sizes -- by length.
Flattening Test -- NPS 2 and larger.
Bending Test(Cold) -- NPS 2 and under.

	Degree of Bend	Diameter of Mandrel
For Normal ASTM A106 uses	90	12 x nom. dia. of pipe
For Close Coiling	180	8 x nom. dia. of pipe

ASTM A106 Grade B Pipe Wall Thickness

ASTM A106 Grade B Pipe Types	Out diameter	Wall thickness	Length
ASTM A106 Grade B Seamless Pipe (Custom Sizes)	1/2" NB - 60" NB	SCH 5 / SCH 10 / SCH 40 / SCH 80 / SCH 160	Custom
ASTM A106 Grade B Welded Pipe (in Stock + Custom Sizes)	1/2" NB - 24" NB	As per requirement	Custom
ASTM A106 Grade B ERW Pipe (Custom Sizes)	1/2" NB - 24" NB	As per requirement	Custom
ASTM A106 Grade B SAW Pipe	16" NB - 100" NB	As per requirement	Custom

Differences In Chemical Composition of A106b Pipe Material

Standard	Grade	Chemical Composition %
Standard	Grade	C	Mn	P	S	Si	Cr	Cu	Ni	Mo	V
ASTM A106	B	≤0.30	0.29-1.06	≤0.035	≤0.035	>0.10	≤0.40	≤0.40	≤0.40	≤0.15	≤0.08
ASTM A53	B	≤0.30	≤1.20	≤0.05	≤0.045	-	≤0.40	≤0.40	≤0.40	≤0.15	≤0.08
API 5L	B(PSL-1)	≤0.28	≤1.20	≤0.030	≤0.030	-	-	-	-	-	-
DIN 1629, DIN 2448	St 37.0	≤0.17	-	≤0.040	≤0.040	-	-	-	-	-	-
DIN 1629, DIN 2448	St 44.0	≤0.21	-	≤0.040	≤0.040	-	-	-	-	-	-
EN10210	S235JRH	≤0.17	≤1.40	≤0.040	≤0.040	-	-	-	-	-	-
GB/T8163, GB/T8162	10#	0.07-0.13	0.35-0.65	≤0.035	≤0.035	0.07-0.37	≤0.15	≤0.25	≤0.30	-	-
GB/T8163, GB/T8162	20#	0.17-0.23	0.35-0.65	≤0.035	≤0.035	0.17-0.37	≤0.25	≤0.25	≤0.30	-	-

A106 Grade B Pipe Differences In Mechanical Composition

Standard	Grade	Tensile Strength (MPa)	Yield Strength (MPa)	Trans.Elongation (%)	Impact Test (J)
ASTM A106	B	>415	≥240	≥16.5	-
ASTM A53	B	>415	≥240	-	-
API 5L	B(PSL-1)	>414	≥241	As clause a	-
DIN 1629	St 37.0	350-480	≥235	≥23	-
DIN 2448	St 44.0	420-550	≥275	≥19	-
EN10210	S235JRH	360-510	≥235	≥26	27 (+20°C)
GB/T 8163	10#	335-475	≥205	≥24	-
GB/T 8162	20#	410-550	≥245	≥20	-

ASTM A106 Gr B Sch 40 Line Pipe pressure rating

Maximum Allowable Pressure (psi)
NPS	Outside Diameter	Schedule
(in)	(in)	10	20	30	STD	40	60	XS	80	100	120	140	160	XXS
1/4	0.54				7985	7985		10798	10798
3/8	0.675				6606	6606		9147	9147
1/2	0.84				6358	6358		8575	8575				10908	17150
3/4	1.05				5273	5273		7187	7187				10220	14373
1	1.315				4956	4956		6670	6670				9316	13340
1 1/4	1.66				4133	4133		5638	5638				7380	11276
1 1/2	1.9				3739	3739		5158	5158				7247	10316
2	2.375				3177	3177		4498	4498				7097	8995
2 1/2	2.875				3460	3460		4704	4704				6391	9408
3	3.5				3024	3024		4200	4200				6132	8400
3 1/2	4				2769	2769		3896	3896
4	4.5				2581	2581		3670	3670		4769		5782	7339
5	5.563				2273	2273		3303	3303		4404		5505	6606
6	6.625				2071	2071		3195	3195		4157		5318	6390
8	8.625		1420	1574	1829	1829	2307	2841	2841	3375	4085	4613	5147	4971
10	10.75		1140	1399	1664	1664	2279	2279	2708	3277	3847	4558	5128	4558
12	12.75		961	1268	1441	1560	2160	1922	2644	3244	3843	4324	5042	3843
14	14	875	1092	1313	1313	1533	2079	1750	2625	3283	3829	4375	4921
16	16	766	956	1148	1148	1531	2009	1531	2585	3157	3733	4404	4882
18	18	681	849	1192	1021	1530	2042	1361	2553	3147	3743	4252	4848
20	20	613	919	1225	919	1455	1989	1225	2526	3138	3675	4288	4824
22	22	557	835	1114	835		1949	1114	2506	3063	3619	4176	4733
24	24	510	766	1147	766	1405	1978	1021	2489	3126	3700	4210	4786
30	30	510	817	1021	613			817
32	32	478	766	957	574	1054
34	34	450	721	901	540	992
36	36	425	681	851	510	1021
42	42		583	729	438	875

ASTM A106 GR. B Carbon Steel Pipe Traders, A106 Grade B seamless pipe stockist, A106 Gr B Sch 40 pipe dealer, Exporter of SA106 Grade B material, ASTM A106 Gr B Material, ASTM A106 Grade B Pipe, A106 Gr b welded pipe manufacturers in India

A106 Grade B Seamless Pipe schedule chart & sizes

NB	Size	OD	40S	5S	10S	S10	S20	S40	S60	XS/80S	S80	S100	S120	S140	S160	XXS
NB	Size	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm	mm
	1/8”	10.29			1.2			1.73			2.41
	1/4”	13.72			1.7			2.24			3.02
	3/8”	17.15			1.7			2.31			3.2
15	1/2”	21.34	2.8	1.7	2.1			2.77		3.73	3.73				4.78	7.47
20	3/4”	26.67	2.9	1.7	2.1			2.87		3.91	3.91				5.56	7.82
25	1”	33.4	3.4	1.7	2.8			3.38		4.55	4.55				6.35	9.09
32	1 1/4”	42.16	3.6	1.7	2.8			3.56		4.85	4.85				6.35	9.7
40	1 1/2”	48.26	3.7	1.7	2.8			3.68		5.08	5.08				7.14	10.2
50	2”	60.33	3.9	1.7	2.8			3.91		5.54	5.54				9.74	11.1
65	2 1/2”	73.03	5.2	2.1	3.1			5.16		7.01	7.01				9.53	14
80	3”	88.9	5.5	2.1	3.1			5.49		7.62	7.62				11.1	15.2
90	3 1/2”	101.6	5.7	2.1	3.1			5.74		8.08	8.08
100	4”	114.3	6	2.1	3.1			6.02		8.56	8.56		11.1		13.5	17.1
125	5”	141.3	6.6	2.8	3.4			6.55		9.53	9.53		12.7		15.9	19.1
150	6”	168.3	7.1	2.8	3.4			7.11		10.97	11		14.3		18.3	22
200	8”	219.1	8.2	2.8	3.8		6.4	8.18	10.3	12.7	12.7	15.1	19.3	20.6	23	22.2
250	10”	273.1	9.3	3.4	4.2		6.4	9.27	12.7	12.7	15.1	19.3	21.4	25.4	28.6	25.4
300	12”	323.9	9.5	4	4.6		6.4	10.3	14.3	12.7	17.5	21.4	25.4	28.6	33.3	25.4
350	14”	355.6	9.5	4	4.8	6.4	7.9	11.1	15.1	12.7	19.1	23.8	27.8	31.8	35.7
400	16”	406.4	9.5	4.2	4.8	6.4	7.9	12.7	16.7	12.7	21.4	26.2	31	36.5	40.5
450	18”	457.2	9.5	4.2	4.8	6.4	7.9	14.3	19.1	12.7	23.8	29.4	34.9	39.7	45.2
500	20”	508	9.5	4.8	5.5	6.4	9.5	15.1	20.6	12.7	26.2	32.5	38.1	44.5	50
550	22”	558.8	9.5	4.8	5.5	6.4	9.5		22.2	12.7	28.6	34.9	41.3	47.6	54
600	24”	609.6	9.5	5.5	6.4	6.4	9.5	17.5	24.6	12.7	31	38.9	46	52.4	59.5
650	26”	660.4	9.5			7.9	13			12.7
700	28”	711.2	9.5			7.9	13			12.7
750	30”	762	9.5	6.4	7.9	7.9	13			12.7
800	32”	812.8	9.5			7.9	13	17.5		12.7
850	34”	863.6	9.5			7.9	13	17.5		12.7
900	36”	914.4	9.5			7.9	13	19.1		12.7

Schedule 40 ASTM A106 Grade B Pipe Surface Finish

Surface Finishes: Bare, Oiled, Mill Varnish, Galv, FBE, FBE Dual, 3LPE, 3LPP, Coal Tar, Concrete Coating and Tape Wrap.
End Finishes: Beveled, Square Cut, Threaded & Coupled.

ASTM A106 Gr B ERW Pipe Applications

ASTM A106 Grade B Steel Pipe is used in the most critical engineering applications and also in certain applications in the automotive sector. In addition, some of the value-added Carbon Steel products include steel for LPG cylinders, API grade, corrosion resistant steel, critical structural application steel, boiler quality, auto grades, precision tubes and medium/high carbon grades, among others.

ASTM A106 Grade C Pipe mostly used in:

Refineries
Power Plants
Boilers
Ship Building
Heat Exchangers
Condensers
Paper & Pulp
Marine Applications
Nuclear Power
Fossil Fuel Power Plants

A106 Grade B Pipes Chemical Material Composition

	Grade A	Grade B	Grade C
Carbon max. %	0.25	0.30	0.35
Manganese %	0.27 to 0.93	0.29 to 1.06	0.29 to 1.06
Phosporous, max. %	0.025	0.025	0.025
Sulfur, max. %	0.025	0.025	0.025
Silicon, min. %	0.10	0.10	0.10

A106 Carbon Steel Pipes Mechanical Properties Database

Seamless	Grade A	Grade B	Grade C
Tensile Strength, min., psi	48,000	60,000	70,000
Yield Strength, min., psi	30,000	35,000	40,000

ASME SA 106 Gr B Pipe Equivalent

	Former		New
Execution	Standard	Material	Standard	Material
Seamless	ASTM A106	GRADE B	EN 10216-2	P265GH

ASTM A106 Grade A Pipe Packaging & Shipping

ASTM A106 Grade B Schedule 160 & ASTM A106 Sour Service Pipe both are loose or in bundles tightened with Iron Strips. Special packings: Metal or Wooden Cases, Pallets etc.

Marking Requirements
Rolled, die stamped, or paint stenciled (manufacturer’s option).

Manufacturer’s name, brand, or trademark
A106 A, A106 B, or A106 C
Hydrostatic test pressure and/or NDE, or NH if neither is specified
Size, length, weight per foot (NPS 4 and larger)
ANSI schedule number or weight class or wall thickness
Additional “S” if tested supplementary requirements

Tags:

Stainless Steel Coil

Stainless Steel Sheet Plate

Stainless Steel Pipe Tube

Stainless Steel Bars

Stainless Steel Strip

Stainless Steel Welding Wire

Stainless Steel Channel

Carbon Steel Coil

Carbon Steel Plate Sheet

Carbon Steel Pipe Tube

Carbon Steel Bar

Galvanized Steel Plate

Galvanized Steel Coil

Galvanized Steel Wire

ERW Carbon Steel Pipe Tube Sch 40 A106 SA 106 Gr B Welded

Sch 40 Carbon Steel Pipe Tube

A106 Carbon Steel Pipe Tube

Carbon Steel ERW Pipe

ASTM A106 Grade B Carbon Steel Pipe Size Range

Carbon Steel A106 Seamless Pipes Price list

SA 106 Gr B Welded Pipes Outside Diameter

ASTM A106 grade b seamless pipe Mechanical Tests Specified

ASTM A106 Grade B Pipe Wall Thickness

Differences In Chemical Composition of A106b Pipe Material

A106 Grade B Pipe Differences In Mechanical Composition

ASTM A106 Gr B Sch 40 Line Pipe pressure rating

ASTM A106 GR. B Carbon Steel Pipe Traders, A106 Grade B seamless pipe stockist, A106 Gr B Sch 40 pipe dealer, Exporter of SA106 Grade B material, ASTM A106 Gr B Material, ASTM A106 Grade B Pipe, A106 Gr b welded pipe manufacturers in India

A106 Grade B Seamless Pipe schedule chart & sizes

Schedule 40 ASTM A106 Grade B Pipe Surface Finish

ASTM A106 Gr B ERW Pipe Applications

A106 Grade B Pipes Chemical Material Composition

A106 Carbon Steel Pipes Mechanical Properties Database

ASME SA 106 Gr B Pipe Equivalent

ASTM A106 Grade A Pipe Packaging & Shipping

Q235B Cold Rolled Steel Square Tube,

Q235 Welded Square Steel Pipe,

Stainless Steel Coil

Stainless Steel Sheet Plate

Stainless Steel Pipe Tube

Stainless Steel Bars

Stainless Steel Strip

Stainless Steel Welding Wire

Stainless Steel Channel
